Multi Skimmer System

Overview

Multi Skimmer System is designed to recover loating oil with a very low water up rate between 2 – 5%.

Login to see prices | unit(s)

SKU: PID.002.140.MS.001 Categories: , , , , ,

Description

Features :

  • Capacity is up to 5 m3 per hour
  • Skimmer head weighs approximately 25 kg
  • Skimming modules can be easily changed from disc to brush or drum
  • Body material is fiber
  • Pneumatic System drives the Transfer Pump and skimmer
  • Application for ports, harbors, rivers and coastal areas

Technical Data :

Skimmer Head :

Body G.R.P
No. of Disc 10 in 1 Bank
No. of Brush 1 in 1 Bank
Disc Speed Variable Speed Controlled by Air Regulator System
Skimmer Capacity 5 m3/h

Power Pack :

Working Pressure 120 Psi (8.4 Bar / 0.84 MPa)
Type Self Priming, Positive Displacement Pump
Drive Air Operated / Pneumatic System
Net Weight Approx. 9 Kg
Suction/ Discharge 38.1 mm (1.5 inches) Camlock
