PRODUCT'S DETAIL
Multipurpose Service Container
Previous
|
Overview
CONTAINER is designed and manufactured to be used in transporting and storage of Oil Spill Equipment, such as: Oil Boom, Oil Skimmer, Oil Storage, and other Oil Spill Response Equipment
Login to see prices | unit(s)
Description
Features :
- The Container has double doors and complete with a lifting equipment set
- The Container has two types : offshore or onshore
- The Container is built in accordance with ISO 668:1995 (Classifcation Dimension & Rating) and BS EN 12079-1:2006 (Lifting Test) and BUREAU VERITAS RULES
Technical Data :
| Type | 20 ft ISO Container Side Doors | 10 ft ISO Container | 10 ft Offshore Service Container | 10 ft Offshore Containerized Hydraulic Winder |
| Length (mm) | 6058 | 2991 | 2991 | 2991 |
| Width (mm) | 2440 | 2438 | 2438 | 2438 |
| Height (mm) | 2590 | 2591 | 2591 | 2591 |
| Max. Gros Mass | 10000 kg | 6500 kg | 11500 kg | 11500 kg |
| Main Structure | JIS SS 400 Or Equal | 6 mm JIS SS 400 Or Equal | ||
| Corner Casting | SCW 49 | 25 mm ASTM A519 GR 70 or Equal | ||
| Coating | 3 Layers of Hempel or Equal | |||
